Chemical resistant
- gasoline crude, benzene,sodium, hydrochloric acid.

Travel speed
- Straight line : 200 m/min
- Curved line : 50 m/min

Minimum ambient temperatures
- Bending stress limit : 831 kp/㎠(831 x 14.2psi)
- Tensile strength : 491 kp/㎠, Elongation 3.2 %
- Breaking strength : 345 kp/㎠, Elongation 36 %

Electrical properties
- Voltage : AC 600V
- Creepage path : min. 30㎜
- Dielectric strength : 31.2 kv/mm
- Surface resisistance : 10 ohm(Dry)
- Protection class : IP 23 with rubber covering




Minimum ambient temperatures
- 30℃ to + 60℃(standard design)

Minimum curve radius
- Minimum : R = 600 mm(4pole)

Max curve length
 - Maximum : L = 3,500 mm

Calculation of Voltage-Drop
AC  : △u = √ 3 x J x I x Z / 1000
DC : △u = 2I x J x R / 1000
         △u = Voltage(V)
            J = Amperage(A)
            Z = Impedance ohms / 1000(m)
            R = Resistance ohms / 1000(m)
            L = Length(m)
             I = L Power feed positioned at end
                  L/2 Power feed positioned at center
